Auxx Attic Lift

Regular price $2,245.00
Sale price $2,245.00 Regular price $3,845.00
Unit price
Compare Ask a question

Ask a Question

* Required fields

 Size guide Share

DESCRIPTIONS

With the Auxx Attic Lift, You Can Unlock Hidden Space and Improve Your Home Storage Experience

Accept the independence of space with the Auxx Attic Lift, a potent tool made to remove debris with ease. With a 400 lb lifting capacity, this cutting-edge equipment expands your storage options. The Auxx Lift Attic Lift does more than just provide storage; it also makes your attic easily accessible, removing the risk of mishaps and hassles associated with using a ladder. Easily adjusted with a wireless remote, a range of platform sizes, and vertical travel options according to your preferences.


Up to 400 pounds of lifting capacity: Easily lift and store large objects, reducing the difficulties associated with hand lifting.

Platform size options: Select a platform size between 20.75 x 44 in and 28.75 x 56 in to precisely meet your storage requirements.

Vertical Travel Options: Choose between 12 and 18 feet, providing adaptable storage options for varying ceiling heights. You can also establish high and low point parameters with the Auxx Attic Lift's programmed stopping points to keep your stuff from collapsing through the ceiling or floor.

Sky-High Storage: The Auxx Lift Attic Lift effectively uses the often-overlooked attic space in your home to increase storage capacity throughout.

Wireless Convenience: The user-friendly wireless remote control makes it easy to raise and lower objects, simplifying operation.

Maximum Safety: With self-leveling platform technology, weight monitoring, and additional safety measures that guarantee a secure storage experience, you can enjoy peace of mind.

Hassle-Free Attic Access: Increase the accessibility of your attic and steer clear of the inconveniences and mishaps associated with using a ladder.

Tough Platform Design: The robust and adaptable T-slotted framing rail design offers stability and longevity while supporting a range of objects.

Elegant Decking: The 3/4-inch oak veneered plywood sheet (5-ply) that makes up the decking gives your stored belongings a sturdy base while also adding a refined touch.

Dual Motor Power: Synced motors improve performance and dependability by ensuring level and seamless platform movement.

Aircraft Cable: Sturdiness and strength are ensured by the 7x19 vinyl-coated galvanized steel aircraft cable.

Proudly Assembled in the USA: Made with love in the United States, every Auxx Attic Lift is a tribute to the excellence and workmanship of the country.

2-year warranty: Enjoy peace of mind with a 2-year warranty that demonstrates the Auxx Attic Lift's faith in its robustness and dependability.

60 Days Money Back Guarantee: With a generous 60-day money-back guarantee, you can try the Auxx Lift Attic Lift risk-free and be assured of your happiness.

Cut Out Dimensions:

  • The 20.75" x 44" attic lift requires a minimum 22.5" x 46.5" cutout
  • The 28.75" x 56" attic lift requires a minimum 30.5 x 58.5" cutout
  • These are minimum ceiling opening dimensions. The opening may be larger.

What’s Included:

  • Dual Synchronized Motors capable of lifting up to 400 pounds
  • Lifter Controller with Optional Stopping Point Programming
  • Remote Control via Wireless
  • Two Channels for C-Strut
  • Attic-Lift Platform (20.75 x 44 in. and 28.75 x 56 in. Size Options) with Oak Veneered Plywood Decking
  • Robust Aluminum T-Slotted Platform Structure

SPECIFICATIONS

General specs

  • Model: Attic-Lift 1400
  • Lifting Capacity: Up to 400 lbs
  • Max. Travel Distance: 16 ft

Ceiling Support

  • Type: (2) 1 5/8" x 60" strut channel
  • Fasteners: (8) 5/16" x 4" SPAX© Lag Bolts
  • Mounting Area: 5' x 5' over 3 joists/rafters
  • Cable: 1/8” Vinyl-coated Steel 7x19
  • Cable Strength (Ultimate tensile strength): 2,000 lbs

Operating Requirements

  • Switch Voltage: 110V / 120V
  • Transmitter: 433.92 MHz
  • Electrical Cord: 10 FT / 16 gauge / NEMA 5-15
  • Min. circuit size: 15 amp

Platform Specs

  • Material: 6105-T5 aluminum alloy
  • Deking: 3/4 in thick Oak veenered plywood (5-ply)
  • The platform frame is constructed with a versatile T-slotted framing rail made from 6105-T5 aluminum alloy. The long sides are made with 2 x 1 solid double T-slot and the short sides use 1 x 1 solid T-slotted beams. Tensile Strength: 35,000 psi

Motors

  • Type: IP44 (T-Motor)
  • Rated Power: 235 W
  • Rated Current: 2.2 A
  • Voltage / Phase: 100-120V AC / Single
  • Duty Cycle @ Max. Capacity: 3 min on, 15 min off. (If you run the Attic-Lift continuously for more than 3 min at a time, the motors will switch off automatically and require to cool down for 15 min or less.)


Size and Weight

  • Platform Size 1: 20.75 in x 44 in
  • Platform Size 2: 28.75 in x 56 in
  • Ceiling Cutout Size: See image below for minimum ceiling cutout opening dimensions. Opening may be larger.

INSTALLATION

For installation please call 805-907-9322
